Hi all,

I use the router bridge method to profile my cores. I'm pretty satisfied with my setup, not that fast but I get quite accurate results.
I tried the planer crib method in the past but I only have a very cheap planer (-> not that accurate) and I couldn't find the perfect/easiest way to secure the core on the crib..

Anyway the choice of profiling method is not the question...
As some might have noticed, profiling cores generates a lot of dust and the router bridge method is worse that planer as you don't have a dust port directly on the machine.

How do you guys deal with all the dust with router bridge ?

Today I tried to build a "wall" all around my vacuum table setup but it makes manipulating the bridge cumbersome and the fine dust goes all over the place anyways.
I tried to attach my dust collector hose on the bridge, facing the vacuum able -> useless, it grabs some wood chips here and there but a lot of chips/dust flies everywhere.

I was thinking of adding some brushes on the bridge itself to "enclose" the chip projection and somehow plug my dust collector so it "sucks" inside this enclosure (like on CNC routers)... don't know if it will help.

something like that :


Any ideas / pics / thoughts ?

I was thinking of some kind of skirt with a hole drilled next to the router for dust. Basically what's in the picture there.

Eventually when I have a CNC I'll have 5hp dust collector with a 5" hose on each side of the router.

Is it possible to get a dust pickup accessory for your router?

Here is my dust collector on my cnc router. I used 3/4 MDF and then cut my firehose as the "fingers". I have 2-1" pvc tubing running on each side of the router that ties into my shop vac. It is only attached to my router by friction so it slides off easily when I am changing out bits.
[/img]

skidesmond -> I don't think so, it's an old Porter Cable router, an old version of this one (http://www.deltaportercable.com/Product ... ctID=11095)

COsurfer -> I can't see your pic from work, will have a look at it later but I believe it's the same thing I want to try.

Ben, I was thinking something similar.
Putting a skirt around my sled.
I'm still trying to puzzle out the hook up to the dust collector.
Have you made any progress on this?
Any thoughts?
I'm getting tired of having to clean up half my basement after making a core.

sam

Hi Sam,

I made a skirt around the sled out of some door sill rubber thing. Not the best choice of material, I should have taken some real strip brush like the one from McMaster, but it works OK. It's just a bit stiff so sometimes it lifts the sled when I change direction. I did with what was available fast, locally and cheap.
I'll take pics later today to show you the sled.

Unfortunately I can't show it to you in action as I temporarily converted my vacuum base in a screen printing vacuum table.

Ben

This is kind of off the wall but what about using the bristles from a paint brush?.. Cut the handle off and glue/fasten the rest of the brush to the base some how..... Just a thought.

Yes that's a great idea ! Might give it a try wen I rebuilt the bridge with a "factory-built-in" dust port...

Here are the pics :
Top view


Bottom view


How I modified my dust collector hose to fit 2X 2-1/4" vacuum hose


I wanted to have 2 smaller ports so I can have suction over each core and remove dust over the whole width of the vacuum table. The hoses just hang from the ceiling when I profile cores, it works OK !
One improvement I have to make is cover the unused section of the groove in the bridge (the section the router is not covering), the only dust that can escape my system is through this groove, I have some ideas on how to do this.

Also, here is my screen printing test setup, re-using the vacuum table to hold the topsheet material. Hopefully tests should be done early this week, I just have to wait for my friend whose job is screen printing to give me a hand on how to prepare the ink and make the first print.




Also, 3 pairs that are just waiting for the topsheet to be done :

Awesome,
I never would have thought to attach the dust collector to the sled separately!
I was also thinking about using brushes to seal off where the router goes thru the sled. Gonna take some trial and error to get it right.

Might have to work on this this set off.

Thanks Ben!

sam

Jumped in my car this morning to run some errands, looked down on the floor and there it was.
The answer I was looking for.



or more specifically this.



I'll probably need 8 or 10 of them but they are only $2 each.

Now to find the port adapters.

More as this develops.

sam

This is what you're looking for. McMaster part numbers: 74405T71, 8813T2.

Many pics show these in use here: http://www.happymonkeysnowboards.com/MonkeyBlog/?p=246

Good luck!

Mike
